Buffer Tanks

Buffer Tanks

(ZCBT, ZHBT)

Features

Chilled Water Buffer Tanks (ZCBT) are designed for use in chilled water systems with insufficient water volume capacity
Zilmet Hot Water Buffer Tanks (ZHBT) are designed for us with today’s high efficiency systems that have low mass boilers
Integral Ring Stand for Vertical Installation
Top Air Vent Connection
Optional : 1/2″ Elastomeric insulation , weather resistant coating
Available with 1/2″ – 2″ NPT connections
Available in either 2 or 4 ports
1″ – 20″ flange connections also available

Specifications

All ASME rated Buffer Tanks are designed, and constructed to confirm to ASME Section VIII, Div I

Material: carbon steel
Maximum pressure: 125 PSIG
Maximum temperature 450F
Finish: Red oxide primer
1 year warranty

Brochure

Heating Catalog

Manuals & Submittals

Hot Water Buffer Tanks 4 Port Data Submittal

Hot Water Buffer Tank 2 Port Data Submittal

Chilled Water Buffer Tank Data Submittal
